The Newest and Fashionable Rigid Core Flooring

The Newest and Fashionable Rigid Core Flooring

Description:

Item:TYM501

Thickness: 4.0mm~8.0mm
Wear Layer: 0.2mm~0.7mm
Underlay(Optional):EVA/ IXPE, 1.0mm~2.0mm
Size:12” X 24”/ 12” X 12”/ Customization

tub_4 tub_5tub_7tub_1

SPC vinyl flooring is made from the mix of limestone and vinyl resin, it is one of the most popular types of flooring both in residential and commercial applications. 100% waterproof, new generation Eco-friendly ground covering, perfect impact resistance, etc. are all its typical features, as the newest type of flooring nowadays, it is the ideal solution for ground covering everywhere.


Product Detail

Product Detail:

dd4c2fd0

It may be a question when someone looks for a type covering of ground decoration for the yard, especially when you want the flooring of your corridor or some specific area in your yard to be different, not just the traditional way it shows. With the emerging of SPC flooring, now it isn’t a question anymore. As a new generation flooring type with rigid core, from its structure we could know you’ll never need to worry about its durability, and then with the water resistance which is a basic feature required by a yard in daily life, you will have the water to the flowers, the water to the trees, so that means if you want to use a flooring in your yard, you must find one that 100% resistant to the water, SPC flooring is such kind of flooring. Because SPC flooring is 100% waterproof, no matter how you use the water with the flooring, never need to worry, SPC flooring can always live together with water. Adding to one of its other features as its strong impact resistance, as a ground covering in your yard or outside area in your home, SPC flooring, with its strong wear layer and UV layer, features s super strong durability, which brings you a hassle-free flooring solution.

tub_2

Specification

Surface Texture

Wood Texture

Overall Thickness

4mm

Underlay(Optional)

IXPE/EVA(1mm/1.5mm)

Wear Layer

0.2mm. (8 Mil.)

Width

12” (305mm.)

Length

24” (610mm.)

Finish

UV Coating

Locking System

tub_6

Application

Commercial & Residential



Technical Data:

tub_9SPC RIGID-CORE PLANK TECHNICAL DATA

Technical Information

Test Method

Results

Dimensional

EN427 &
ASTM F2421

Pass

Thickness in total

EN428 &
ASTM E 648-17a

Pass

Thickness of wear layers

EN429 &
ASTM F410

Pass

Dimensional Stability

IOS 23999:2018 & ASTM F2199-18

Manufacturing Direction ≤0.02% (82oC @ 6hrs)

Across Manufacture Direction ≤0.03% (82oC @ 6hrs)

Curling (mm)

IOS 23999:2018 & ASTM F2199-18

Value 0.16mm(82oC @ 6hrs)

Peel Strength (N/25mm)

ASTM D903-98(2017)

Manufacturing Direction 62 (Average)

Across Manufacture Direction 63 (Average)

Static Load

ASTM F970-17

Residual Indentation:0.01mm

Residual Indentation

ASTM F1914-17

Pass

Scratch Resistance

ISO 1518-1:2011

No penetrated the coating at the load of 20N

Locking Strength(kN/m)

ISO 24334:2014

Manufacturing Direction 4.9 kN/m

Across Manufacture Direction 3.1 kN/m

Colour Fastness to Light

ISO 4892-3:2016 Cycle 1 & ISO105–A05:1993/Cor.2:2005& ASTM D2244-16

≥ 6

Reaction to fire

BS EN14041:2018 Clause 4.1 & EN 13501-1:2018

Bfl-S1

ASTM E648-17a

Class 1

ASTM E 84-18b

Class A

VOC Emissions

BS EN 14041:2018

ND – Pass

ROHS/Heavy Metal

EN 71-3:2013+A3:2018

ND – Pass

Reach

No 1907/2006 REACH

ND – Pass

Formaldehyde emission

BS EN14041:2018

Class: E 1

Phthalate Test

BS EN 14041:2018

ND – Pass

PCP

BS EN 14041:2018

ND – Pass

Migration of Certain Elements

EN 71 – 3:2013

ND – Pass

Packing Infornation:

Packing Information(4.0mm)

Pcs/ctn

12

Weight(KG)/ctn

22

Ctns/pallet

60

Plt/20’FCL

18

Sqm/20’FCL

3000

Weight(KG)/G.W

24500
