Modern Art Grey Cement Flooring Tile

Modern Art Grey Cement Flooring Tile

Description:

ItemTYM 510

Thickness: 4.0mm~8.0mm

Wear Layer0.2mm~0.7mm

Underlay(Optional)EVA/ IXPE, 1.0mm~2.0mm

Size12” X 24”/ 12” X 12”/ Customization

cer010

The TopJoy floor design team has designed a series of floors that mimic cement texture to meet the aesthetics of young people. These mimic cement surface planks are not only can be used as flooring, but also the wall surface with our advanced installation system.


Product Detail

Technical Data

Packing Information

a2

With the diversification of interior decoration styles, more and more people like modern minimalist or personalized industrial style decoration styles. The floor surface is one of the most important decorative materials in the entire space, and it determines the main tone of the space style. TopJoy TYM510 modern art concrete floor is specially designed for those fashionable avant-garde decoration style and commercial places, such as cafes, restaurants, art exhibition venues, etc. As a completely environmentally friendly flooring material, TopJoy SPC flooring has good waterproof performance, and then its surface hardness can almost reach the effect similar to that of the cement floor, such as abrasion resistance, slip resistance, colorfastness, etc... Therefore, its perfect performance is enough for it to be used in humid places, such as basement rooms, bathrooms, kitchens. At the same time, it can be installed on the wall in the shower rooms.

a1

Specification

Surface Texture

Wood Texture

Overall Thickness

4mm

Underlay(Optional)

IXPE/EVA(1mm/1.5mm)

Wear Layer

0.3mm. (12 Mil.)

Width

12” (305mm.)

Length

24” (610mm.)

Finish

UV Coating

Click

a3

Application

Commercial & Residential


  • Previous:
  • Next:

  • SPC RIGID-CORE PLANK TECHNICAL DATA

    Technical Information

    Test Method

    Results

    Dimensional

    EN427 &
    ASTM F2421

    Pass

    Thickness in total

    EN428 &
    ASTM E 648-17a

    Pass

    Thickness of wear layers

    EN429 &
    ASTM F410

    Pass

    Dimensional Stability

    IOS 23999:2018 & ASTM F2199-18

    Manufacturing Direction ≤0.02% (82oC @ 6hrs)

    Across Manufacture Direction ≤0.03% (82oC @ 6hrs)

    Curling (mm)

    IOS 23999:2018 & ASTM F2199-18

    Value 0.16mm(82oC @ 6hrs)

    Peel Strength (N/25mm)

    ASTM D903-98(2017)

    Manufacturing Direction 62 (Average)

    Across Manufacture Direction 63 (Average)

    Static Load

    ASTM F970-17

    Residual Indentation:0.01mm

    Residual Indentation

    ASTM F1914-17

    Pass

    Scratch Resistance

    ISO 1518-1:2011

    No penetrated the coating at the load of 20N

    Locking Strength(kN/m)

    ISO 24334:2014

    Manufacturing Direction 4.9 kN/m

    Across Manufacture Direction 3.1 kN/m

    Colour Fastness to Light

    ISO 4892-3:2016 Cycle 1 & ISO105–A05:1993/Cor.2:2005& ASTM D2244-16

    ≥ 6

    Reaction to fire

    BS EN14041:2018 Clause 4.1 & EN 13501-1:2018

    Bfl-S1

    ASTM E648-17a

    Class 1

    ASTM E 84-18b

    Class A

    VOC Emissions

    BS EN 14041:2018

    ND – Pass

    ROHS/Heavy Metal

    EN 71-3:2013+A3:2018

    ND – Pass

    Reach

    No 1907/2006 REACH

    ND – Pass

    Formaldehyde emission

    BS EN14041:2018

    Class: E 1

    Phthalate Test

    BS EN 14041:2018

    ND – Pass

    PCP

    BS EN 14041:2018

    ND – Pass

    Migration of Certain Elements

    EN 71 – 3:2013

    ND – Pass

    bottom01

    Packing Information(4.0mm)

    Pcs/ctn

    12

    Weight(KG)/ctn

    22

    Ctns/pallet

    60

    Plt/20’FCL

    18

    Sqm/20’FCL

    3000

    Weight(KG)/G.W

    24500
