TYM102-02

TYM102-02

Description:

Item:TYM102-02
Thickness: 4.0mm~8.0mm

Wear Layer: 0.2mm~0.7mm
Underlay(Optional):EVA/ IXPE, 1.0mm~2.0mm
Size:12” X 24”/ 12” X 12”/ Customization

tub_4 tub_5tub_7tub_1



The unique of SPC flooring is its rigid core elements.It can withstand all from scratches and stains to spills and sond. SPC can be the floor that you want which looks and performs its best.


Product Detail

Product Detail:

dd4c2fd0

Every wise property owners should take advantage of SPC vinyl flooring to update their room or offices with the latest trending flooring. The SPC Vinyl flooring should be your first choice with for being durable, light weight, versatile and low maintenance requirements.

SPC Vinyl flooring, or Rigid core Vinyl flooring as it’s also known, offers comfort in hard-surface flooring that no other can compare, while at the same time it is one of the most affordable flooring options. Because SPC Vinyl floor is made of limestone composite PVC, it offers you with softer and warmer underfoot feeling than the other hard surface floors. SPC Vinyl flooring is also incredibly durable and easy to maintain.

tub_2

Specification

Surface Texture

Wood Texture

Overall Thickness

4mm

Underlay(Optional)

IXPE/EVA(1mm/1.5mm)

Wear Layer

0.2mm. (8 Mil.)

Width

12” (305mm.)

Length

24” (610mm.)

Finish

UV Coating

Locking System

tub_6

Application

Commercial & Residential

Technical Data:

tub_9SPC RIGID-CORE PLANK TECHNICAL DATA

Technical Information

Test Method

Results

Dimensional

EN427 &
ASTM F2421

Pass

Thickness in total

EN428 &
ASTM E 648-17a

Pass

Thickness of wear layers

EN429 &
ASTM F410

Pass

Dimensional Stability

IOS 23999:2018 & ASTM F2199-18

Manufacturing Direction ≤0.02% (82oC @ 6hrs)

Across Manufacture Direction ≤0.03% (82oC @ 6hrs)

Curling (mm)

IOS 23999:2018 & ASTM F2199-18

Value 0.16mm(82oC @ 6hrs)

Peel Strength (N/25mm)

ASTM D903-98(2017)

Manufacturing Direction 62 (Average)

Across Manufacture Direction 63 (Average)

Static Load

ASTM F970-17

Residual Indentation:0.01mm

Residual Indentation

ASTM F1914-17

Pass

Scratch Resistance

ISO 1518-1:2011

No penetrated the coating at the load of 20N

Locking Strength(kN/m)

ISO 24334:2014

Manufacturing Direction 4.9 kN/m

Across Manufacture Direction 3.1 kN/m

Colour Fastness to Light

ISO 4892-3:2016 Cycle 1 & ISO105–A05:1993/Cor.2:2005& ASTM D2244-16

≥ 6

Reaction to fire

BS EN14041:2018 Clause 4.1 & EN 13501-1:2018

Bfl-S1

ASTM E648-17a

Class 1

ASTM E 84-18b

Class A

VOC Emissions

BS EN 14041:2018

ND – Pass

ROHS/Heavy Metal

EN 71-3:2013+A3:2018

ND – Pass

Reach

No 1907/2006 REACH

ND – Pass

Formaldehyde emission

BS EN14041:2018

Class: E 1

Phthalate Test

BS EN 14041:2018

ND – Pass

PCP

BS EN 14041:2018

ND – Pass

Migration of Certain Elements

EN 71 – 3:2013

ND – Pass

Packing Infornation:

Packing Information(4.0mm)

Pcs/ctn

12

Weight(KG)/ctn

22

Ctns/pallet

60

Plt/20’FCL

18

Sqm/20’FCL

3000

Weight(KG)/G.W

24500
