Waterproof Rigid Core Vinyl Flooring Plank

Waterproof Rigid Core Vinyl Flooring Plank

Description:

Item:TJ10581-KB1





Thickness: 4.0mm~8.0mm

Wear Layer: 0.2mm~0.7mm
Underlay(Optional):EVA/ IXPE, 1.0mm~2.0mm
Size7.25’’ X 48’’/ 6’’X48’’/ 9’’X48’’/ 7’’X36’’/ 6’’X36’’/ 9’’X36’’/ Customization

tub_4 tub_5tub_7tub_1

Water proof Rigid Core Vinyl flooring is not only 100% waterproof and fire-resistant, but it also provides dimensional stability, durability and, impact resistance up to 20 times that of current laminate flooring technology. It combines with a design that replicates the aesthetic and natural variation of hardwood creates truly uncompromising flooring for your home.


Product Detail

dd4c2fd0



TOPJOY Rigid Core Vinyl flooring Plank Loyal Court color a versatile flooring product applicable not only at residential rooms but also at commercial places. Its wood visual has taken over the residential units as it offers the development owners a realistic wood pattern at a fraction of the cost of real wood. Commercial spaces utilize wood patterns in many instances, however organic visuals offer businesses an opportunity to be creative and create unique spaces.

This Loyal court color rigid core vinyl plank is not radiating elegant and classic style but also holding its dimensional stability and integrality. Thanks to its unique structure, which including a stone core and a durable, scratch-resistance wear layer to match plus a UV coating, the plank is the most durable one built for toughest environment.

The rigid core vinyl plank gives you peace of mind for years to come.

全景

tub_2

Specification

Surface Texture

Wood Texture

Overall Thickness

4mm

Underlay(Optional)

IXPE/EVA(1mm/1.5mm)

Wear Layer

0.2mm. (8 Mil.)

Width

7.25” (184mm.)

Length

48” (1220mm.)

Finish

UV Coating

Locking System

tub_6

Application

Commercial & Residential



Technical Data:

SPC RIGID-CORE PLANK TECHNICAL DATA

Technical Information

Test Method

Results

Dimensional

EN427 &
ASTM F2421

Pass

Thickness in total

EN428 &
ASTM E 648-17a

Pass

Thickness of wear layers

EN429 &
ASTM F410

Pass

Dimensional Stability

IOS 23999:2018 & ASTM F2199-18

Manufacturing Direction ≤0.02% (82oC @ 6hrs)

Across Manufacture Direction ≤0.03% (82oC @ 6hrs)

Curling (mm)

IOS 23999:2018 & ASTM F2199-18

Value 0.16mm(82oC @ 6hrs)

Peel Strength (N/25mm)

ASTM D903-98(2017)

Manufacturing Direction 62 (Average)

Across Manufacture Direction 63 (Average)

Static Load

ASTM F970-17

Residual Indentation:0.01mm

Residual Indentation

ASTM F1914-17

Pass

Scratch Resistance

ISO 1518-1:2011

No penetrated the coating at the load of 20N

Locking Strength(kN/m)

ISO 24334:2014

Manufacturing Direction 4.9 kN/m

Across Manufacture Direction 3.1 kN/m

Colour Fastness to Light

ISO 4892-3:2016 Cycle 1 & ISO105–A05:1993/Cor.2:2005& ASTM D2244-16

≥ 6

Reaction to fire

BS EN14041:2018 Clause 4.1 & EN 13501-1:2018

Bfl-S1

ASTM E648-17a

Class 1

ASTM E 84-18b

Class A

VOC Emissions

BS EN 14041:2018

ND - Pass

ROHS/Heavy Metal

EN 71-3:2013+A3:2018

ND - Pass

Reach

No 1907/2006 REACH

ND - Pass

Formaldehyde emission

BS EN14041:2018

Class: E 1

Phthalate Test

BS EN 14041:2018

ND - Pass

PCP

BS EN 14041:2018

ND - Pass

Migration of Certain Elements

EN 71 – 3:2013

ND - Pass



Packing Infornation:

Packing Information(4.0mm)

Pcs/ctn

12

Weight(KG)/ctn

22

Ctns/pallet

60

Plt/20’FCL

18

Sqm/20’FCL

3000

Weight(KG)/G.W

24500
