Ultimate Durability Easy Installation Stone Pattern Engineered Vinyl Flooring

Ultimate Durability Easy Installation Stone Pattern Engineered Vinyl Flooring

Description:

ItemTYM 202-2

Thickness: 4.0mm~8.0mm

Wear Layer0.2mm~0.7mm

Underlay(Optional)EVA/ IXPE, 1.0mm~2.0mm

Size12” X 24”/ 12” X 12”/ Customization

cer010

By choosing engineered vinyl flooring in the stone pattern, you can enjoy the beauty of materials like slate, artfully captured in stone-look vinyl flooring. Any room of your home is OK, even under high traffic, high moisture, and high impact.


Product Detail

Technical Data

Packing Information

a2

Engineered Vinyl Flooring is known for being unparalleled durability and 100% waterproof. It is set apart from other types of vinyl flooring by its uniquely resilient core layer. This core is made from a combination of natural limestone powder, polyvinyl chloride, and stabilizers. This provides an incredibly stable base for each flooring plank. Special stone styles, pattern TYM 202-2, create a dramatic look that’s perfect for any room, even under high traffic, high moisture and high impact.

By using a patented Unilin click system, it can be installed by yourself and save the labor cost. They can be placed on top of many different types of subfloors or existing flooring. Simply click into place will be OK, eliminating the need for messy and complicated glues.

a1

Specification

Surface Texture

Wood Texture

Overall Thickness

4mm

Underlay(Optional)

IXPE/EVA(1mm/1.5mm)

Wear Layer

0.3mm. (12 Mil.)

Width

12” (305mm.)

Length

24” (610mm.)

Finish

UV Coating

Click

a3

Application

Commercial & Residential


  • Previous:
  • Next:

  • SPC RIGID-CORE PLANK TECHNICAL DATA

    Technical Information

    Test Method

    Results

    Dimensional

    EN427 &
    ASTM F2421

    Pass

    Thickness in total

    EN428 &
    ASTM E 648-17a

    Pass

    Thickness of wear layers

    EN429 &
    ASTM F410

    Pass

    Dimensional Stability

    IOS 23999:2018 & ASTM F2199-18

    Manufacturing Direction ≤0.02% (82oC @ 6hrs)

    Across Manufacture Direction ≤0.03% (82oC @ 6hrs)

    Curling (mm)

    IOS 23999:2018 & ASTM F2199-18

    Value 0.16mm(82oC @ 6hrs)

    Peel Strength (N/25mm)

    ASTM D903-98(2017)

    Manufacturing Direction 62 (Average)

    Across Manufacture Direction 63 (Average)

    Static Load

    ASTM F970-17

    Residual Indentation:0.01mm

    Residual Indentation

    ASTM F1914-17

    Pass

    Scratch Resistance

    ISO 1518-1:2011

    No penetrated the coating at the load of 20N

    Locking Strength(kN/m)

    ISO 24334:2014

    Manufacturing Direction 4.9 kN/m

    Across Manufacture Direction 3.1 kN/m

    Colour Fastness to Light

    ISO 4892-3:2016 Cycle 1 & ISO105–A05:1993/Cor.2:2005& ASTM D2244-16

    ≥ 6

    Reaction to fire

    BS EN14041:2018 Clause 4.1 & EN 13501-1:2018

    Bfl-S1

    ASTM E648-17a

    Class 1

    ASTM E 84-18b

    Class A

    VOC Emissions

    BS EN 14041:2018

    ND – Pass

    ROHS/Heavy Metal

    EN 71-3:2013+A3:2018

    ND – Pass

    Reach

    No 1907/2006 REACH

    ND – Pass

    Formaldehyde emission

    BS EN14041:2018

    Class: E 1

    Phthalate Test

    BS EN 14041:2018

    ND – Pass

    PCP

    BS EN 14041:2018

    ND – Pass

    Migration of Certain Elements

    EN 71 – 3:2013

    ND – Pass

    bottom01

    Packing Information(4.0mm)

    Pcs/ctn

    12

    Weight(KG)/ctn

    22

    Ctns/pallet

    60

    Plt/20’FCL

    18

    Sqm/20’FCL

    3000

    Weight(KG)/G.W

    24500
