DIY Click Installation Rigid Core Luxury Vinyl Plank

DIY Click Installation Rigid Core Luxury Vinyl Plank

Description:

Item:UC1107-5



Thickness: 4.0mm~8.0mm

Wear Layer: 0.2mm~0.7mm
Underlay(Optional):EVA/ IXPE, 1.0mm~2.0mm
Size:7.25’’ X 48’’/ 6’’X48’’/ 9’’X48’’/ 7’’X36’’/ 6’’X36’’/ 9’’X36’’/ Customization

tub_4 tub_5tub_7tub_1

Rigig core vinyl flooring have come a long way since their humble beginnings as a less expensive alternative to traditional hardwood floors. One thing that has not changed is the affordability – but the quality is through the roof! Our vinyl floors have a real wood look and texture that is easy to install and even easier to maintain.


Product Detail

dd4c2fd0



Traditional vinyl floors are composed of almost entirely PVC and, at temperatures above 80-90F, start to expand and lose stability. In practice, this has meant that vinyl plank could not be safely recommended in spaces that reach temperatures above 90F or in installations where the longest run was above 35 feet.

We, TopJoy, addressed this issue by reformulating the core of our planks to a majority-limestone composite. By using up to 70% limestone content in the core of our planks, we create the uniquely “rigid” property of our floors. Not only does the high limestone content mean less expansion and contraction to begin with, but it also means that when expansion and contraction does occur the floors can handle it.

Anyone looking for a durable, long-lasting floor that enhances the look of any space and won't break the bank. Rigid core vinyl flooring are perfect for you!



UC1107-5下面大图



tub_2

Specification

Surface Texture

Wood Texture

Overall Thickness

4mm

Underlay(Optional)

IXPE/EVA(1mm/1.5mm)

Wear Layer

0.2mm. (8 Mil.)

Width

7.25” (184mm.)

Length

48” (1220mm.)

Finish

UV Coating

Locking System

tub_6

Application

Commercial & Residential



Technical Data:

SPC RIGID-CORE PLANK TECHNICAL DATA

Technical Information

Test Method

Results

Dimensional

EN427 &
ASTM F2421

Pass

Thickness in total

EN428 &
ASTM E 648-17a

Pass

Thickness of wear layers

EN429 &
ASTM F410

Pass

Dimensional Stability

IOS 23999:2018 & ASTM F2199-18

Manufacturing Direction ≤0.02% (82oC @ 6hrs)

Across Manufacture Direction ≤0.03% (82oC @ 6hrs)

Curling (mm)

IOS 23999:2018 & ASTM F2199-18

Value 0.16mm(82oC @ 6hrs)

Peel Strength (N/25mm)

ASTM D903-98(2017)

Manufacturing Direction 62 (Average)

Across Manufacture Direction 63 (Average)

Static Load

ASTM F970-17

Residual Indentation:0.01mm

Residual Indentation

ASTM F1914-17

Pass

Scratch Resistance

ISO 1518-1:2011

No penetrated the coating at the load of 20N

Locking Strength(kN/m)

ISO 24334:2014

Manufacturing Direction 4.9 kN/m

Across Manufacture Direction 3.1 kN/m

Colour Fastness to Light

ISO 4892-3:2016 Cycle 1 & ISO105–A05:1993/Cor.2:2005& ASTM D2244-16

≥ 6

Reaction to fire

BS EN14041:2018 Clause 4.1 & EN 13501-1:2018

Bfl-S1

ASTM E648-17a

Class 1

ASTM E 84-18b

Class A

VOC Emissions

BS EN 14041:2018

ND - Pass

ROHS/Heavy Metal

EN 71-3:2013+A3:2018

ND - Pass

Reach

No 1907/2006 REACH

ND - Pass

Formaldehyde emission

BS EN14041:2018

Class: E 1

Phthalate Test

BS EN 14041:2018

ND - Pass

PCP

BS EN 14041:2018

ND - Pass

Migration of Certain Elements

EN 71 – 3:2013

ND - Pass



Packing Infornation:

Packing Information(4.0mm)

Pcs/ctn

12

Weight(KG)/ctn

22

Ctns/pallet

60

Plt/20’FCL

18

Sqm/20’FCL

3000

Weight(KG)/G.W

24500
